CHISEL PLOW

SIMPLE MACHINES

• Screws- To hold the Machine Together
• Lever- To Adjust The Depth
• Wedge- to turn up the dirt
• Pulley- to move the digger up and down
• Wheel axle- both to move it

WEDGE

• It up-turns the dirt ( main goal)
• They also create drag to keep it down
• Bottom

WHEEL AND AXLE

• There is both
• To let it move
• On the bottom
• On the top

LEVER

• To rise and lever the chisel plow
• Lets the farmer stay in the cab
• In the cab

SCREW

• Hold it together
• Found all over

PULLY

• The lever moves the pulley
• Found on the back of the tractor

Now on to Forces

FUN FACT
The Chisel Plow is Considered the most important tillage tool!!!

FORCES

• Gravity
• Friction
• Thrust
• Drag
• Pressure, Momentum

GRAVITY

• Stay on the ground to dig up dirt
• Balanced
• Contact

THRUST

• Moves it go forward
• Unbalanced
• Contact

FRICTION

• In order to stop
• To go down to start digging
• Contact
• Both balanced and unbalanced

DRAG

• To stop
• Across the ground to dig up rows
• Unbalanced
• Contact

PRESSURE

• The plow pushes down to the ground
• So it can dig down deeper
• Gages
• Contact
• Unbalanced

MOMENTUM

• The tractor pulls the the plow
• Contact
• Balanced
